Load balancing

Distribution, health checks, and node scaling

What fails first as traffic grows is rarely one machine running out of power. It is every request landing on that one machine. Requests meet a single entry, then go out to healthy backend nodes.

  • Layer 4 / Layer 7
  • Health-check removal
  • Sticky sessions
  • Bare-metal nodes

Size the nodes from peak concurrency

Growth makes the architecture problems visible

Take single points, bottlenecks, and downtime out of the architecture.

One server cannot hold the peak

Every request hits the same machine. CPU and connections top out, and extra machines never see the traffic.

Adding a machine mid-event does not save the day

One failure takes the whole site down

When the entry and the application share one machine, a hardware fault or a crashed process takes the site offline.

One hardware fault is a full outage

Scaling means downtime and lost sessions

Changing the architecture means a late-night outage. After a node switch, logins disappear and carts can be emptied.

Scaling waits for dawn and hopes sessions survive

Far-away visitors get a worse path

Sending all traffic back to one region detours distant users. Buying bandwidth in every region stacks the cost.

Distant users stay slow, and bandwidth is paid twice

Which workloads should start with load balancing

Peaks, logins, many regions, and releases without downtime all need the entry split from the backends.

Fit

Campaigns and sales

Typical case

A short burst fills one machine, and a machine added mid-event never receives requests.

How to size it

Split the entry from the backends. Add nodes for the peak, then remove them when the campaign ends.

Fit

Services that cannot stop

Typical case

The entry and the application share one machine, so one fault takes the site offline.

How to size it

A failed health check removes that node. The remaining healthy nodes keep the traffic.

Fit

Releases that need a canary

Typical case

A new version needs downtime, and a problem means rolling the whole site back.

How to size it

Put the new version on part of the group and shift a share of traffic. On a problem, send traffic back to the old nodes.

Requests enter one entry, then reach healthy nodes

Health checks decide who receives traffic. Failed nodes drop out, canary traffic moves by share, and sessions stay in sync.

Load balancing from visitors to observation Requests enter a Layer 4 or Layer 7 entry. Health checks send them to healthy nodes, failed nodes are removed, canary traffic moves by share, and sessions stay in sync. Visitors Entry Backends Sessions Observe Health Canary Removed Sync MainlandMainland requests OverseasCross-region entry Mobile and APIAPIs and long connections CrawlersCrawler traffic LB entryLayer 4 and Layer 7 Health checkRemove failed nodes Canary groupShift a share of traffic Sticky sessionOne user, one node Server poolAdd nodes sideways Healthy nodeTakes live traffic Canary nodeA small share first Removed nodeNo new requests Session syncLogins survive a move Read/write splitReads and writes split Raid and backupArray and live backup Traffic monitorWatch health and flow Access logEntry and node records Multi-siteNearby by data center Spare nodeTakes over on failure
  • Normal distribution and canary shift
  • Failed nodes are removed
  • Sticky sessions, backup, and logs

Resources and facilities

Entry, backend, and hardening are sized on different terms.

  • Entry, backend nodes, and hardening nodes can be chosen separately
  • Backend nodes can be added or removed without changing the entry
Entry servers
The entry uses dedicated servers already on sale, sized by concurrent connections.
Backend nodes
The backend pool runs on bare metal, starting at E5-2620. Add a node instead of replacing the architecture.
Public-edge hardening
The public entry can add a high-defense server with 50G DDoS protection, ahead of the business nodes.
Line and bandwidth
US nodes can use CN2 or a mainland-optimized line. Asia-Pacific nodes are often 20M dedicated.
Sites and regions
Backend nodes can sit close to users across 12+ regions, including the US, Hong Kong, Japan, and Germany.
Scheduling and monitoring
Layer 4 and Layer 7 listeners, health checks, and session persistence. Failed nodes are removed and returned.

Recommended setups

Entry, backend, and hardening are chosen separately. Specs and prices follow the product page.

Role / model CPU Memory Disk Line Bandwidth Defense IPv4 From Order
US-E3-1230v3 E3-1230V3·4C / 8T 32G 1T SSD CN2 Direct Pro 30M / 不限流量 10G 3 IPs $79 /mo Order
HK-E3-1230V3 E3-1230V3·4C / 8T 32G 1T SSD CN2 Direct Pro 10M / 不限流量 20G 3 IPs $89 /mo Order
US-LA-E5-2620 E5-2620·6C / 12T 32G 1T HDD China Direct Pro 100M / 不限流量 10G 5 IPs $99 /mo Order
US-E5-2630x2 E5-2630 x 2·12C / 24T 32G 1T SSD CN2 Direct Pro 30M / 不限流量 10G 3 IPs $109 /mo Order

The entry is sized by forwarding rules and the connection table. Backends scale out with concurrency. Hardening stays on the public entry that is actually exposed.

Prices follow the product page. CPU, memory, and disk not listed can be configured. Quarterly 5% off, half-year 10% off, yearly 15% off, and renewals use the same price.

How concurrency sets node count and probe settings

Nodes = peak concurrency ÷ connections per node, plus spare capacity. Probe settings follow the pool size.

Peak connections Backend nodes 1,000 connections each Backend nodes 2,000 connections each max_fails / fail_timeout Session persistence
500 2 2 1 / 10s (default) ip_hash
1,000 2 2 1 / 10s (default) sticky cookie
5,000 6 4 2 / 10s sticky cookie
10,000 11 6 2 / 10s sticky learn
50,000 51 26 3 / 15s sticky learn
100,000 101 51 3 / 15s sticky learn + slow_start
200,000 201 101 3 / 15s sticky learn + slow_start

Nodes = peak concurrency ÷ connections per node, rounded up, plus 1. At 5,000 connections and 1,000 per node, 5,000 ÷ 1,000 = 5, plus 1 spare is 6. At 2,000 per node, 5,000 ÷ 2,000 rounds up to 3, plus 1 is 4. 1,000 and 2,000 are planning figures, not the NGINX default. max_conns defaults to 0, which means unlimited, and should match what one machine can actually hold.

Default probe and session settings

Setting Default What it controls Common mistake
max_fails 1 Failures inside fail_timeout before a node is marked down Ignored when the pool has only one server
fail_timeout 10s Window for counting failures, and how long a node stays down 10 seconds is too sharp when the network jitters, so nodes flap
slow_start 0 (off) How long a recovered node's weight climbs from 0 to its set value Without it, a recovered node is flooded at once
max_conns 0 (unlimited) Maximum active connections on one backend Without it, one node can be crushed
queue timeout 60s How long a request waits when no upstream is free; then 502 A long queue turns 502s into a pile-up
Consistent hash Layer 4 only Adding or removing a backend remaps only a few keys Layer 7 does not support it, so a scale-out drops the cache together
sticky learn session store 1 MB zone ≈ 4,000 sessions Sessions sit in shared memory on 64-bit platforms A growing store evicts older sessions
sticky session timeout 10 minutes A session with no further visits is removed A long mobile session is treated as a new one
backup unmarked (off) Takes traffic only when every primary server is down Using the spare as a second everyday pool
down / drain unmarked (off) down removes it; drain only finishes requests already bound Deleting a server for a short removal remaps every hash

Two traps: with only one server in the pool, max_fails, fail_timeout, and slow_start are ignored, so that server is never marked down. Consistent hash is Layer 4 only. A cache backend on Layer 7 loses the cache together each time you scale out.

Capabilities

Scheduling, removal, sessions, canary release, and node changes, each with a deliverable practice.

The scheduling entry and backend nodes in a data center

From the entry to the nodes, delivered item by item

Requests reach one entry first. Layer 4 forwards connections. Layer 7 splits by domain and URL. Health checks remove failed nodes, sticky sessions work with cluster sync, and a canary shifts only part of the traffic. Nodes change with peak concurrency. The entry config stays.

Layer 4 forwards TCP connections for databases, long connections, and non-HTTP protocols. Layer 7 routes HTTP by domain and URL.

What it means for traffic scheduling: The right layer means the architecture does not have to be rebuilt later.

A failed check isolates that node, and new requests stop going there. When it recovers, it rejoins the group.

What it means for traffic scheduling: One failed machine is no longer a full outage.

One user stays on one node, with cluster session sync. Logins remain when nodes are added or removed.

What it means for traffic scheduling: Scaling no longer clears the cart or the login.

The new version lands on part of the group and receives a small share first. On a problem, traffic returns to the old nodes.

What it means for traffic scheduling: Rollback does not need a redeploy, and the service stays up.

Add backend nodes sideways for the new traffic. The entry and the policy stay. After the peak, take nodes out of the group.

What it means for traffic scheduling: Scaling does not wait for dawn and does not replace the architecture.

Support

After launch, the policy and the node count can still follow the peak.

First reply within 30 minutes on workdays

First reply within 30 minutes on workdays. Nights and weekends cover outages only.

Standard delivery in 30 to 60 minutes

A standard setup is delivered in 30 to 60 minutes. A custom setup takes 1 to 2 workdays.

12 or more regions

Covers the United States, Hong Kong, Japan, Singapore, Germany, and 12 or more regions in total.

Help with architecture and policy

We help set listeners, forwarding policy, and health checks. Parameters follow your peak, not a copied default.

Redundant storage

Raid arrays and live data-center backup mean one disk failure does not stop the service.

99.9 percent availability target

Network availability targets 99.9 percent. Bandwidth and backend nodes can change with the business.

Tell us the architecture, and we will suggest a traffic plan

How many backend servers, which protocols, how far daily traffic sits from the peak, where users are, and whether releases must stay online — share these and we will suggest the scheduling setup and a price.

  • Scheduling advice from the servers you already run
  • Node count and a price from peak concurrency
  • Help with listeners, forwarding rules, and health checks
  • First reply within 30 minutes on weekdays, and nodes can change later

Frequently asked questions

Usually no. The load balancer sits at the entry. Backends only listen on the right port and join over the private network. If the application keeps session files on local disk, say so while we scope the plan.

The site does not go down as a whole. A failed check isolates that node, new requests stop landing there, and other healthy nodes keep serving. When it recovers, it rejoins the group.

Sticky sessions keep one user on one node. With cluster session sync, logins stay when nodes change. Existing users are unaffected. New users are placed in the group that includes the new nodes.

It depends on the protocol and how fine the split must be. Layer 4 forwards TCP connections for databases, long connections, and non-HTTP protocols. Layer 7 routes HTTP by domain and URL. The wrong layer means rebuilding the architecture, not editing one line.

No. Add backend nodes sideways for the new traffic. The entry and the policy stay. After the peak, remove nodes from the group to control cost.

Deploy the new version to part of the group and send it a small share first. When it is stable, increase the share. On a problem, send all traffic back to the old nodes. Rollback does not redeploy.

Node count equals peak concurrency divided by the per-node connection tier, rounded up, plus 1 spare. At 5,000 peak connections and 1,000 per node, that is 5 plus 1 spare, 6 nodes. At 2,000 per node, it is 3 plus 1. Fill the tier from a real single-machine test. max_conns defaults to 0, which means no limit.

The check is usually too strict. One failure inside a 10 second window pulls a node out during a brief network blip, then puts it back. Raise the failure count to 2 or 3, and stretch the window to 10 or 15 seconds. After recovery, turn on slow start so weight climbs from zero instead of taking a full burst at once. A group with only one node ignores the failure count, so keep at least two nodes if removal should work.

Layer 4 forwards the TCP connection and does not rewrite the payload, so the backend sees the entry as the source. For the real client address, Layer 7 adds X-Forwarded-For or X-Real-IP and the application logs that header. Layer 4 needs PROXY protocol on both the entry and the backend. Do not rate-limit on the entry IP alone, or every user looks like one source.

Long connections, WebSocket, and database protocols should use Layer 4 and stay as TCP. Layer 7 fits short HTTP requests that split by domain and URL. If the Layer 7 idle timeout is shorter than the keepalive, the entry closes the connection. Keep sticky sessions on, or later packets from the same connection can land on another node.
