High-bandwidth plan

Dedicated bandwidth, unmetered, built for heavy traffic

On-sale servers cover dedicated ports from 10 Gbps to 40 Gbps. International BGP carries overseas and worldwide delivery. Nodes include the United States, Germany, Hong Kong and Kuala Lumpur.

  • 10 Gbps and above, dedicated
  • No monthly traffic cap
  • International BGP
  • Carried on high-bandwidth servers

10, 20 and 40 Gbps dedicated tiers can be raised in place

Capacity ladder: pick a tier by peak traffic

Five roles, from 10G upward. Specs and the monthly price follow the product page.

10G dedicated, starter

US-SV-XL-E5-2620x2-4SSD

E5-2620 x 2·12C / 24T 128G 1T SSD×4 Global BGP 10G / 不限流量

$929 /mo

Order

10G dedicated, high core count

US-SV-XL-E5-2683v4x2-6SSD

E5-2683v4 x 2·32C / 64T 128G 1T SSD×6 Global BGP 10G / 不限流量

$1069 /mo

Order

10G dedicated, Europe

DE-FRA-XL-E5-2683v4x2-6SSD

E5-2683v4 x 2·32C / 64T 128G 1T SSD×6 Global BGP 10G / 不限流量

$1249 /mo

Order

20G dedicated

US-SV-XL-E5-2697x2-12SSD

E5-2697 x 2·24C / 48T 128G 1T SSD×12 Global BGP 20G / 不限流量

$1739 /mo

Order

40G dedicated

US-SV-XL-Gold-6133x2-6NVME

Gold6133 x 2·40C / 80T 128G 1T NVMe×6 Global BGP 40G / 不限流量

$3069 /mo

Order

For visitors in mainland China, use a mainland-optimized line or premium CN2. The live tier and route are confirmed with sales.

Four choices to settle first

Most quality problems are not about the monthly total. One part of the path is simply the wrong size.

Pick the route before the bandwidth

If visitors are mainly in mainland China, use a mainland-optimized line or CN2. For overseas and worldwide delivery, use international BGP.

The wrong route stays slow even with more bandwidth

Size the tier to the peak, not the average

Live video, downloads and client updates spike. Leave headroom for the peak.

An average-sized port still stalls in the evening peak

Read the traffic policy and the port rate together

Unmetered traffic removes the monthly quota. The port rate decides whether the link can actually fill.

A traffic policy alone does not mean the port can run full

The hardware has to keep up with the port

A port above 10 Gbps needs CPU cores, memory and NVMe storage sized to the same tier.

The port can fill while the machine cannot process it

Which workloads need this much bandwidth

Each scene has a bandwidth scale. The conversion is bandwidth divided by 8, in MB/s.

Fit

Live video and online classes

Typical case

Count a 1080p60 stream at 6 Mbps. Live traffic spikes, so the port should not be bought from the daily average.

How to size it

A 10 Gbps port tops out near 1,600 concurrent streams (10,000 divided by 6). Leave room for the moment many streams start together.

Fit

Video on demand and short video

Typical case

Count one title at 4 Mbps. CDN usually serves playback. The origin has to carry the cache misses.

How to size it

A 20 Gbps port tops out near 5,000 simultaneous plays (20,000 divided by 4). Do not put origin fill and viewer traffic on the same exit.

Fit

Large data transfer and research

Typical case

A single machine fills 10 Gbps only if the disks can keep writing. Settle storage before the port.

How to size it

An NVMe array moves the limit to storage. A larger port still will not fill if the disks cannot take the write.

Set the route first, then open the port to the peak

Downstream traffic enters a dedicated port and is opened to 10, 20 or 40 Gbps. International BGP faces the world, the mainland-optimized line faces mainland visitors, and the server holds the origin while monitoring watches the peak.

From visitor traffic to a dedicated port and the origin Visitor traffic enters a dedicated port and opens to 10, 20 or 40 Gbps. International BGP faces the world. The mainland-optimized line and CN2 face mainland visitors. Content sits on the high-bandwidth server, and monitoring watches peaks that approach the tier ceiling. Visitors Dedicated port Routes Origin Watch Port Route Alert Watch Live viewersStreams enter the port On-demand viewersPlayback requests Download clientsInstaller delivery Shared exitCrowded at the peak Dedicated portNot shared 10 GbpsEntry and origin 20 GbpsPlayback and delivery 40 GbpsA short peak International BGPOverseas and worldwide Mainland optimizedFor mainland visitors CN2Toward mainland China Peak alertNear the tier ceiling OriginFill and delivery High-bandwidth serverHolds the content NVMe storageKeeps up with the port Traffic watchLive query Peak alertCapacity planning Origin pathApart from visitors Data syncOff the visitor port
  • Downstream traffic
  • Peak alert near the tier ceiling
  • Monitoring, route changes and sync

What the port includes

Port, traffic policy, route and hardware, listed so the tier can be judged from the peak.

  • Mainland visitors can move to a mainland-optimized line or CN2. The live tier follows the commercial confirmation
  • Raising bandwidth in the same room does not reinstall the system or move data. A room change does
Port rate
On-sale tiers cover dedicated 10, 20 and 40 Gbps. Dedicated means the port is not shared with other customers.
Traffic policy
There is no monthly cap and no fair-use threshold. Going over does not add a fee and does not slow the port. Unmetered is not the same as an unlimited port rate.
Route
International BGP carries overseas and worldwide delivery. When visitors are mainly in mainland China, use a mainland-optimized line or CN2.
Nodes
On-sale machines are in Silicon Valley, Frankfurt, Hong Kong and Kuala Lumpur. Pick the room from where the users are.
Hardware
CPU cores, memory and SSD or NVMe follow the bandwidth tier. 10 Gbps machines commonly have 128 GB of memory. 40 Gbps needs more disk and more cores.
Delivery and upgrades
A standard setup is delivered in 30 to 60 minutes. A custom setup takes 1 to 2 workdays. Raising the tier in the same room does not reinstall or move data.

Recommended high-bandwidth servers

Specs and prices follow the product page. On-sale tiers cover dedicated 10G, 20G and 40G.

Role / model CPU Memory Disk Route Bandwidth Defense IPv4 Price Order
US-SV-XL-E5-2620x2-4SSD E5-2620 x 2·12C / 24T 128G 1T SSD×4 Global BGP 10G / 不限流量 10G 5 IPs $929 /mo Order
US-SV-XL-Gold-6133x2-2NVME Gold6133 x 2·40C / 80T 128G 2T NVMe×2 Global BGP 10G / 不限流量 10G 5 IPs $1079 /mo Order
DE-FRA-XL-E5-2698v4x2-6SSD E5-2698v4 x 2·40C / 80T 128G 1T SSD×6 Global BGP 10G / 不限流量 10G 5 IPs $1299 /mo Order
US-SV-XL-EPYC-7542x2-2NVME EPYC 7542 x 2·64C / 128T 128G 2T NVMe×2 Global BGP 10G / 不限流量 10G 5 IPs $1379 /mo Order

Dedicated means a 10, 20 or 40 Gbps port that is not shared with other customers. The port rate is a hardware ceiling, not a promise that one machine will fill it. Disk IO, the network stack and CPU can hit the limit first. Committed rate, burst and fair-use terms follow the contract. Mainland visitors can use a mainland-optimized line or CN2.

Prices follow the product page. Quarterly billing is 5 percent off, half-year is 10 percent off, yearly is 15 percent off, and renewal uses the same price. US-SV-XL-E5-2620x2-4SSD at $929 per month is $9,475.8 per year, which is $1,672.2 less than $11,148 paid month by month. The same 10 Gbps dedicated port costs more in some rooms because the room and the bandwidth cost more. Pick the room from where the users are.

How to size it: work backward from the workload

Bandwidth divided by 8 is the download rate in MB/s. The table uses ideal full speed so you can see which tier to start from.

Workload Rule of thumb Tier ceiling
Live video and classes 1080p60 at 6 Mbps About 1,600 streams on 10 Gbps
Video on demand 4 Mbps per title, playback mostly on CDN About 5,000 plays on 20 Gbps
CDN origin Keep origin fill apart, 10,000 divided by 8 1,250 MB/s peak on 10 Gbps
Software downloads A 1 GB installer at 10 MB/s per thread About 500 downloads on 40 Gbps
Sync and backup 10 Gbps full for one month About 3,240 TB, or about 1 PB at 30 percent
Large transfers Check sustained disk write before the port The limit moves to NVMe, so a larger port may still not fill

These are ideal full-speed figures. Disk IO, protocol overhead, CDN hit rate and parallel jobs change the result. The 30 percent figure is an assumption, not an industry standard. Origin fill and visitors slow each other down on one exit, so the origin port should stay for cache fill.

Capabilities

A dedicated port, the traffic policy, the hardware and the node locations decide how heavy traffic behaves.

A wide bandwidth beam leaving the data center

From a dedicated port to a nearby node, delivered item by item

The port belongs to the workload and is not shared in the room. There is no monthly cap and no fair-use threshold. The port opens to the tier you bought. CPU, memory and NVMe follow that tier. Machines are on sale in Silicon Valley, Frankfurt, Hong Kong and Kuala Lumpur.

The port belongs to this workload and is not shared with other customers in the room.

What it means for heavy traffic: The peak rate is not split with someone else.

There is no monthly cap and no fair-use threshold. Going over does not add a fee and does not slow the port.

What it means for heavy traffic: Going over the month does not add a bill.

The port is opened to the tier you bought, so the bandwidth can actually fill.

What it means for heavy traffic: You can use the rate you paid for.

CPU cores, memory and SSD or NVMe storage are sized to the same bandwidth tier.

What it means for heavy traffic: The machine can still process the traffic when the port is full.

On-sale machines are in Silicon Valley, Frankfurt, Hong Kong and Kuala Lumpur.

What it means for heavy traffic: Visitors do not have to fetch content across an ocean.

Support

Monitoring, peak handling and a tier you can change decide how the service feels over time.

First reply within 30 minutes on workdays

Nights and weekends cover outages only. Traffic and speed problems are followed up.

Standard delivery in 30 to 60 minutes

A standard setup is delivered in 30 to 60 minutes. A custom setup takes 1 to 2 workdays. Load testing can start after delivery.

Bandwidth can be raised

The tier and the port rate can change with the business. On-sale tiers cover dedicated 10, 20 and 40 Gbps. Raising the tier in the same room does not reinstall or move data.

Live traffic monitoring

Live traffic queries and peak alerts give you a basis for capacity planning, so the tier ceiling does not arrive without warning.

99.9 percent availability target

Network availability targets 99.9 percent.

Help with the environment

We help install the transfer service and the RAID array, then run a load test and tune it. Measure the peak first, then decide whether the tier is enough.

Tell us the traffic, and we will recommend a tier

Workload, where the visitors are, average and peak traffic, and how much of the port is origin fill or sync. From that we recommend the route, the tier and a configuration price.

  • The tier follows the peak and where the visitors are
  • 10G, 20G and 40G each have on-sale machines
  • Help with setup, load testing and tuning
  • First reply within 30 minutes on workdays. The tier can be raised
View products

Frequently asked questions

Dedicated bandwidth is a port reserved for this workload, so daytime and the evening peak behave the same way. Shared bandwidth is used by many customers on one exit, and they crowd each other at the peak. Judge it by three things: port rate, committed bandwidth, and burst or fair-use limits. Peak-sensitive workloads should use a dedicated port.

Look at where the visitors are. Mainland China visitors should use a mainland-optimized line or CN2. Overseas and worldwide delivery should use international BGP.

Traffic is not billed by the month. There is no monthly cap and no fair-use threshold, so volume does not add a fee. Unmetered is not an unlimited port rate. The usable rate is the port you bought: 10, 20 or 40 Gbps.

Three causes are common: the exit is shared, the route does not match where the visitors are, or origin fill, sync and backup compete with visitors on the same port. Measure the real rate during the peak before buying more bandwidth.

Yes. The tier and the port rate can change without redeploying the service or moving data. Fast-growing workloads should leave headroom at the start. A move to another room does need a new deployment, and that is better in a quiet period.

A larger port needs more CPU, memory and disk IO. 10 Gbps machines commonly have 128 GB of memory. A 40 Gbps tier needs more cores and NVMe, such as dual Gold 6133 with 128 GB and several NVMe drives. Confirm the disks can keep writing before you lock the port.

A standard setup is delivered in 30 to 60 minutes, and load testing can start then. Changing CPU, memory or disks takes 1 to 2 workdays. Raising the tier in the same room does not reinstall the system or move data. A different room does need a new deployment.

See whether the port stays full, or only the peak is crowded. A port that sits on the ceiling needs the next tier, from 10 to 20 to 40 Gbps. If only the evening peak drops and the average is low, the route does not match the visitors, and changing the route helps more than adding bandwidth. Neither change needs a data migration.

Prices follow the product page. Quarterly billing is 5 percent off, half-year is 10 percent off, yearly is 15 percent off, and renewal uses the same price. A 20 Gbps machine at $1,739 per month is $17,737.8 per year, which is $3,130.2 less than $20,868 paid month by month. CPU, memory, disk, defense and IPv4 that are not listed can be configured to order.

No. The port rate is a hardware ceiling. Disk IO, the network stack and CPU can hit the limit first. Measure the peak, then decide whether the tier is enough. Above 10 Gbps, CPU, memory and NVMe need to match the same tier.
